FANUC SUPER CAP T / CAP II T Operators manual Page 207

Operators manual
13. SETTING DATA
B–62444E–1/04
OPERATION
194
The following table lists tools that are automatically specified according to the
type of the machining and the area to be machined.
Type of machining Area to be machined Tool
Bar machining and
pattern repeating
Outer surlaco edge Outer–surface machining
Outer non–edge surface Outer–surface machining
Inner surface edge Inner–surface machining
Inner non–edge surface Inner–surface machining
End face edge End–face machining
End face non–edge ma-
chining
End–face machining
Residual machining Outer surface Outer–surface machining
Inner surface Inner–surface machining
End face End–face machining
Inner bottom face Inner bottom face ma-
chining
End facing End–face machining
Threading Outer surface Outer–surface threading
Inner surface Inner–surface threading
Grooving Outer surface Outer–surface grooving
Inner surface Inner–surface grooving
End face End–face grooving
Necking Right side of an outer sur-
face
Outer–surface machining
Left side of an outer sur-
face
Outer–surface machining
Right side of an inner sur-
face
Inner–surface machining
Left side of an inner sur-
face
Inner–surface machining
Upper side of an end face End–face machining
Lower side of an end face End–face machining
Center drilling Center drill
(end face turning)
Drilling Drill
(end face turning)
13.1.15
Automatic Tool
Specification Function
