FANUC SUPER CAP T / CAP II T Operators manual Page 379

Operators manual
1. MACHINING PROGRAMS FOR
2–AXES (X AND Z AXIS) LATHES
B–62444E–1/04
TYPES OF MACHINING
PROGRAMS
368
Use single action II to input more general NC program commands.
Addresses other than O or N can be input. Multiple G codes can also be
specified in a single block.
To use single action II, set bit 0 (SC2) of parameter No. 9766 to 1. Then,
press the [SINGL] soft key in the same way as for the conventional single
action.
PROC(01) HEAD TOOL NO TYPE T–CODE
SINGL ACT HEAD–L 102 SIDE 0101
TOOL NO. : Tool ID number of the tool used for the conventional
single action
TYPE : Screen on which the machining simulation is drawn
Select one of [SIDE], [C–FRONT], [C–OPEN],
[Y–FRONT], or [Y–CROSS].
1. Turning drawing: Turning simulation on the ZX plane is displayed.
2. C–axis end–face drawing: C–axis drilling/grooving/notching
simulation on the XC plane is displayed.
3. C–axis development drawing: Simulation of C–axis cylindrical
machining on the CZ plane is displayed.
4. Y–axis end–face drawing: Y–axis end–face drilling/milling
simulation on the XY plane is displayed.
5. Y–axis side drawing: Y–axis side–face drilling/milling simulation on
the YZ plane is displayed.
NOTE
1 To disable the display of TYPE on the screen, set bit 1 (TYP)
of parameter No. 9766 to 1. Then, the turning drawing is
automatically selected and displayed for turning tools
(including drills), while the end–face drawing is displayed for
milling tools.
T CODE : Tool ID number
This item is used only to select the tool to be displayed in
machining simulation.
To actually output a T code, figure data must be specified.
NOTE
2 Single action II is not supported by the detail data screen.
A product profile cannot be displayed.
1.9.5
Selecting the Type of
Machining (Single
Action II)
1.9.6
Process Data (For
Single Action II)
