FANUC SUPER CAP T / CAP II T Operators manual Page 116

Operators manual
B–62444E–1/04
8. EDITING MACHINING PROGRAMS
OPERATION
103
(1) Using a cursor key, move the cursor to the figure block to be
followed by a new figure.
(2) Press the [INSERT] soft key.
(3) The graphic pattern menu is displayed on the soft keys. Press the soft
key of the figure to be added.
<
°
± ²
ROUND PLOT³ CHAMFR
+
[ + ]
< ¾ ½ ¼ PLOT¿ TANGNT FIGURE
END
+
(4) The input data items for the new contour are displayed in the window
guidance. The color of the frame of the window guidance changes
to yellow. The following soft keys are displayed.
INSERT TOOL–D PLOTCANCEL DETAIL
DATA
If a cursor key is pressed in this state, the yellow inverted cursor moves
in the window guidance.
(5) Using numeric keys, enter the numeric data for the new figure and
press the INPUT key.
(6) After entering all necessary data, press the [INSERT] soft key.
(7) Based on the added figure, the contour is recomputed and the results
are displayed. The color of the frame of the window guidance
returns to sky blue.
8.4.3
Adding a Figure
