B–62444E–1/04

12. DIRECT OPERATION FOR

MACHINING PROGRAMS

CREATED CONVERSATIONALLY

OPERATION

135

By pressing [TOOLING] on the registered–program directory screen,

setting screen before execution, or process directory screen, the tooling

data screen is displayed.

Processes and data for the tools being used are displayed in the order in

which they were registered in the machining program. With [HEAD–L]

or [HEAD–R], a tool post can be selected for display.

Example of tooling data screen: For a two–path lathe

*** HEAD–L TOOLING DATA *** [CAP : HEAD– L]

01/01

PROC PROC NAME USING TOOL GEOMETRY GEOMETRY RN/WN/DD/TR/TW T–CODE

OFS X OFS Z

01 END FACNG (R) –200.000 –10.000 RN 0.400 0202

02 BAR (R) –300.000 –20.000 RN 0.600 0303

03 BAR (F) 0.000 0.000 RN 0.600 0404

04 GROOVING 0.000 0.000 WN 2.000 0505

05 C–GROOVE (R) ENDMILL 0.000 0.000 TR 5.000 0606

06 C–GROOVE (C) CHAMFER 0.000 0.000 TR 10.000 0707

07 CENTERDRL CENTER 0.000 0.000 DD 2.000 0808

08 DRILLING DRILL 0.000 0.000 DD 5.000 0909

09 BORE BORE 0.000 0.000 TW 10.000 1010

10 THREADING OUTR TH 0.000 0.000 RN 0.000 1111

11 C–NOTCHING(R) END MILL 0.000 0.000 TR 5.000 1212

12 C–NOTCHING(F) END MILL 0.000 0.000 TR 5.000 1313

GEOMETRY OFS X

HEAD–

Y–AXIS

OFFSET

WEAR

OFFSET

PRE-

PARE

TOOL

LIFE

TOOL

DISPLY

RETURN

PROC : Process number

PROC NAME : Name of each process

USING TOOL : Symbol or name of a tool used for each process

GEOMETRU OFS X,Z :

Tool geometry compensation values (same as

compensation values for the NC side)

This data item can be entered directly by using the

numeric keys, or can be entered by using the setup

guidance screen for compensation value

measurement, displayed by pressing [PREPARE].

RN/WN/DD/TR/TW: Data specific to each tool

RN= Tool tip radius (same as the compensation

value for the NC)

WN= Width of a grooving tool

DD= Nominal diameter of a drilling tool

TR= Radius of a milling cutter (same as the

compensation value for the NC)

TW= Width of a boring tool

12.1.4

Mounting Tools
