The following parameters in the NC must be set when a conversational
function is used.
1022 Setting axes in the reference coordinate system
To determine the following planes for circular interpolation and tool tip
radius compensation, set each control axis to any one of axes, X, Y, Z in
the reference coordinate system, or an axis parallel to one of the reference
axes. Only one of the reference axes can be specified. Two or more axes
parallel to any of the reference axes can be specified.
G17: Xp–Yp plane
G18: Zp–Xp plane
G19: Yp–Zp plane
Setting Description
0 Axis which is neither a reference axis nor a parallel axis
1 X reference axis
2 Y reference axis
3 Z reference axis
5 Axis parallel to the X–axis
6 Axis parallel to the Y–axis
7 Axis parallel to the Z–axis
D Set the parameter corresponding to the first axis (X–axis) to 1, and the
parameter corresponding to the second axis (Z–axis) to 3. Set the
parameter corresponding to the third axis (C–axis) to 6 if the C–axis
graphic conversion function is provided.
#7
1300
#6 #5 #4 #3 #2 #1 #0
OUT
OUT 1 : The outer end of the second stored stroke limit is treated as the
prohibited area.
0 : The inner end of the second stored stroke limit is treated as the
prohibited area.
D Always set this bit to 0.
#7
GSC3401
#6
GSB
#5 #4 #3 #2 #1 #0
GSB and GSC: Any one of the G code systems is specified.
D Always set both bits to 0 (G code system A).
A.19
