FANUC SUPER CAP T / CAP II T Operators manual Page 592

Operators manual
B–62444E–1/04
A. PARAMETERS
APPENDIX
585
#7
3405
#6 #5 #4
CCR
#3 #2 #1 #0
CCR To specify a corner radius during chamfering,
1 : Addresses I and K are used. In direct programming of a drawing
dimension, “,C” or “,R” are used.
0 : Addresses C and R are used. Address C cannot be used as the name of
a C–axis.
D Always set this bit to 0.
#7
5002
#6 #5
LGC
#4
LGT
#3 #2 #1
LGN
#0
LD1
LD1 1 : The offset No. of tool offset is specified by one digit after the T code.
0 : The offset No. of tool offset is specified by two digits after the T code.
D Always set this bit to 0.
LGN 1 : The upper two digits in the T code indicate a tool geometry
compensation No.
0 : The lower two digits in the T code indicate a tool geometry
compensation No.
D Set this bit corresponding to the PMC.
LGT 1 : The tool geometry is compensated according to tool movement.
0 : The tool geometry is compensated according to the shift of the
coordinate system.
D Always set this bit to 0.
LGC 1 : Tool geometry compensation is canceled by specifying 0 for the offset
No.
0 : Tool geometry compensation is not canceled by specifying 0 for the
offset No.
D Always set this bit to 1.
#7
ANM6500
#6
NZM
#5 #4
CSF
#3
DPA
#2
GUL
#1
SP2
#0
GRN
GRN On the two–spindle graphic display of the FS16/18–TTA,
1 : Tool post 1 is shown on the right and tool post 2 is shown on the left.
0 : Tool post 1 is shown on the left and tool post 2 is shown on the right.
SP2 The graphic display of the FS16/18–TTA shows:
1 : One spindle.
0 : Two spindles.
GUL On the one–spindle graphic display of the FS16/18–TTA, the X1 and X2
axes are displayed:
1 : After they are exchanged.
0 : As they are.
DPA The current position shown on the graphic screen is:
1 : The programmed position.
0 : The actual position obtained after the tool–tip radius compensation is
applied.
D Always set this bit to 0
