13. SETTING DATA
OPERATION
217
(7) Coefficients for boring tools
The feed amount can be increased or decreased according to the range of
the nominal diameter of a boring tool for each material of the tool.
Example of operation to specify coefficients for boring tools)
10 INPUT (NOMINL–D 1)
20
INPUT (NOMINL–D 2)
30
INPUT (NOMINL–D 3)
40
INPUT (NOMINL–D 4)
1.2
INPUT (Coefficient 1–1)
1.1
INPUT (Coefficient 1–2)
1.0
INPUT (Coefficient 1–3)
0.9
INPUT (Coefficient 1–4)
0.8
INPUT (Coefficient 1–5)
0.6
INPUT (Coefficient 2–1)

[CAP. :HEAD–L]
*** MACHINING CONDITION (COEFIC) ***
BORE
NOMINL–D 10 20 30 40
(MM)
CARBID 1.200 1.100 1.000 0.900 0.800
HI–SPD 0.600 0.000 0.000 0.000 0.000
SPCIAL 0.000 0.000 0.000 0.000 0.000
(FEED/REV)
101#L OUTTER T0505 RN 0.400 AC 90 AN 60 TW 20.000
102#R OUTTER T0101 RN 0.400 AC 90 AN 60 TW 20.000
103#R OUTTER T0202 RN 0.400 AC 90 AN 60 TW 20.000
251#L OUTR TH T0404 RN 0.000 AN 60 TW 40.000
252#R OUTR TH T0606 RN 0.000 AN 60 TW 40.000
<
MENU
RETURN
GUIDE
NOTE
The groove width for which coefficient data 1.000 is set (20
mm to 30 mm in the above example) is displayed in the
S–DIA. field of the cutting condition data screen for boring
tools.
