FANUC SUPER CAP T / CAP II T Operators manual Page 589

Operators manual
A. PARAMETERS
B–62444E–1/04
APPENDIX
582
NOTE
This parameter is used to calculate the machining time in
machining simulation.
9891 TFNCTM
TFNCTM: Average time required to execute the tool function
Setting range: 0 to 99999999 Increment: 10 ms
NOTE
This parameter is used to calculate the machining time in
machining simulation.
9892 NCPRGN
NCPRGN: Program number to be searched for automatically when the
conversational mode is switched to the NC mode
Setting range: 0 to 9999
NOTE
This parameter prevents a machining program from being
accidentally executed when machining is started after the
conversational mode is switched to the NC mode.
If this parameter is set to 0, the system does not search for
programs.
9893 GERM1S
GERM1S: M code to be output when the low gear is selected (sub–spindle)
Setting range: 0 to 255
9894 GERM2S
GERM2S: M code to be output when medium gear 1 is selected (sub–spindle)
Setting range: 0 to 255
9895 GERM3S
GERM3S: M code to be output when medium gear 2 is selected (sub–spindle)
Setting range: 0 to 255
