FANUC SUPER CAP T / CAP II T Operators manual Page 80

Operators manual
B–62444E–1/04
6. CREATING MACHINING PROGRAMS
OPERATION
67
(4) Soft keys
The following soft keys are displayed when the cursor is positioned
at the process data items.
<
DELETE
INSERT PRGRM
END
MCHN–C TOOL–
D
PLOTWINDOW
OFF
PROCES
EDIT
DETAIL
DATA
+
[DELETE] : Deletes the current process. Pressing this soft
key displays the following confirmation
message and soft keys.
CANCEL
EXEC
EXEC REALLY? YES:[EXEC] NO:[CANCEL]
Pressing the [EXEC] soft key deletes the process. Pressing the
[CANCEL] key cancels the deletion and returns to the previous state.
[PRGRM END] : Terminates the creation of the program and
returns to the main menu.
[WINDOW OFF] : Suppresses the window guidance. Pressing
this soft key changes the key to the [WINDOW
ON] soft key. Pressing the [WINDOW ON]
soft key displays the window guidance.
[PROCES EDIT] : Displays the process directory screen.
[MCHN–C] : Displays the cutting condition data screen.
[TOOL–D] : Displays the registered–tool directory screen.
[DETAIL DATA] : Displays all the data used in the process.
[PLOT] : Displays figures of a workpiece in all the
processes of the machining program.
