FANUC SUPER CAP T / CAP II T Operators manual Page 50

Operators manual
B–62444E–1/04
4. TYPES OF SCREENS
OPERATION
37
In Super CAP T for two–path lathes used with the Series 16–TB, a screen
for tool post 2 is added to each screen explained in Super CAP T for
one–path lathes used with the Series 16–TB.
A screen for tool post 1 is the same as the corresponding screen explained
in Super CAP T for one–path lathes.
(1) Parameter setting screen (For details, see Part V, Appendix.)
Parameters related to the conversational automatic programming
function are common to tool posts 1 and 2 except for parameter No.
9770 specifying allocation of the NC–format program area and
conversational format program area.
+INPUT INPUT
<
ABB
PARAMETER(CAP BIT PARAM)
9770 NM7 NM3 NM2 NM1 NM0
00000000
9771 1SP 2SP 96S 96M CS2 CLD DM2 T99
00001001
9772 INO DIO RFN YMD RLF EDM MSO CM5
11100000
9773 MDL GTL TCD RPT OPO GRO SG3
01101010
9774 AUT GPW T00 M10 280 MLT MLS TLC
11011001
>_
MDI **** *** *** 13:06:58 HEAD1
ACTUAL POSITION
(ABSOLUTE)
O0001 P0000
(MODAL)
G00 G25 G13.1 F M
G97 G22 S
G69 G80 SRPM 0
G99 G67 SSPM 0 T
G21 G54 SMAX 32767
G40 G18 SACT 0
REL ALL NO.SRH OFF:0ON:1
F 0
MM/M
X1 0.000
Z
1 0.000
C
1 0.000
Y
1 0.000
–
(2) Main menu (For details, see II.6.)
This menu is common to tool posts 1 and 2.
(3) Machining condition data screen (For details, see II.13.)
This screen is common to tool posts 1 and 2.
4.2
TWO–PATH LATHES
