13. SETTING DATA
OPERATION
163
Selecting the tool data screen on the tool data menu screen calls the tool
data directory screen.
REST No. OF TOOL=92 [CAP. :HEAD–L]
<
*** TOOL FILE LIST ***
101#01 OUTTER T0505 RN 0.400 AC 90 AN 60 TW 20.000
102#02 OUTTER T0101 RN 0.400 AC 90 AN 60 TW 20.000
103#02 OUTTER T0202 RN 0.400 AC 90 AN 60 TW 20.000
251#01 OUTR TH T0404 RN 0.000 AN 60 TW 40.000
451#01 OUTR GR T1212 RN 0.000 WN 3.000 AA 90 TL 15.000
452#02 OUTR GR T1212 RN 0.200 WN 3.000 AA 90 TL 5.000
601#01 DRILL T0808 RN 20.000 AC 118 TL 170.000
COPY DELETETRANS. DISPLY
/EDIT
MENU
RETURN
TOOL
ENTRY
No.= →SFTKY
NOTE
The above example shows the tool data directory screen for
the 2–path lathe. In the 1–path lathe, the tool post number
(#L or #R) is not displayed on the right of the tool
management number.
