FANUC SUPER CAP T / CAP II T Operators manual Page 219

Operators manual
13. SETTING DATA
B–62444E–1/04
OPERATION
206
Pressing the [4] soft key on the tool data menu screen displays the cutting
condition data screen for grooving tools.
To display the cutting condition data screen for each tool material, press
the
page key.
Example of operation to specify cutting conditions for rough machining)
. 5 INPUT (FEED/REV.)
80 INPUT (CUT SPD.)
2
INPUT (CUT DPTH)
Example of operation to specify cutting conditions for finish machining)
. 3 INPUT (FEED/REV.)
120 INPUT (CUT SPD.)
[CAP. :HEAD–L]
<
*** MACHINING CONDITION (GROOVING) ***
ROUGHING FINISHING
CARBID BITE (S–WDTH MM∼ MM) CARBID BITE
MATERIAL FEED/REV. CUT SPD. CUT DPTH MATERIAL FEED/REV. CUT SPD.
(MM/REV.) (M/MIN.) (MM) (MM/REV.) (M/MIN.)
FC25 0.5000 80.0 2.000 FC25 0.3000 120.0
FCD45 0.0000 0.0 0.000 FCD45 0.0000 0.0
SS41 0.0000 0.0 0.000 SS41 0.0000 0.0
S45C 0.0000 0.0 0.000 S45C 0.0000 0.0
SKD11 0.0000 0.0 0.000 SKD11 0.0000 0.0
SUS304 0.0000 0.0 0.000 SUS304 0.0000 0.0
AL1 0.0000 0.0 0.000 AL1 0.0000 0.0
AL2 0.0000 0.0 0.000 AL2 0.0000 0.0
MENU
RETURN
WORK
MATERL
SET FEEDRATE AMOUNT BY MAX. VALUE
101#L OUTTER T0505 RN 0.400 AC 90 AN 60 TW 20.000
102#R OUTTER T0101 RN 0.400 AC 90 AN 60 TW 20.000
103#R OUTTER T0202 RN 0.400 AC 90 AN 60 TW 20.000
251#L OUTTER TH T0404 RN 0.000 AN 60 TW 40.000
252#R OUTTER TH T0606 RN 0.000 AN 60 TW 40.000
Because the feed amount required for finish machining for trapezoidal
grooves is calculated based on the surface roughness and radius of the tool
tip, a clamp value for the feed amount needs to be set, as in the cutting
conditions for general–purpose tools.
NOTE
Enter the following three items in the cutting condition data
for grooving tools:
· One of the three tool material types
· Either rough machining or finish machining
· One of the eight (or 24) workpiece material types
Cutting condition data for rough machining is only used for ordinary and
slanted grooves. Cutting condition data for finish machining is used for
trapezoidal grooves.
13.2.3
Cutting Condition Data
for Grooving Tools
Previous page
Next page
