4.AUTOMATIC OPERATION OPERATION B-63784EN-1/01

- 174 -

4.13 MANUAL HANDLE INTERRUPT

In automatic operation, this function allows a move command

generated by the manual pulse generator to be superimposed on a

programmed move command. As a result, the actual tool path deviates

from the programmed path by the amount by which the operator turns

the manual pulse generator. Therefore, this function can give the

operator an additional margin in machining.

Explanations

- Interrupt operation

(1) A manual handle interrupt can be accepted in modes other than

the positioning mode (such as G00).

Even in a block that does not move the tool or when automatic

operation is in the stopped state, a manual handle interrupt can be

accepted unless the positioning mode is effective.

NOTE

- Even if the feedrate override signal is set to 0%, a

manual handle interrupt is accepted.

- In positioning mode, the tool moves at the rapid

traverse rate. Therefore, commands such as G28 and

G29 can also be considered to be positioning mode.

(2) For how to select a target axis for manual handle interrupt, refer to

the manual provided by the machine tool builder.

(3) The speed during manual handle interrupt is the sum of the speed

in automatic operation and that of movement by manual handle

interrupt. The speed, however, is controlled so as not to exceed

the upper cutting feedrate on the axis.

Example

Suppose that the upper limit of the cutting feedrate on a

given axis is 5 m/min. If the tool is moving along that axis in

the positive direction at 2 m/min, the manual pulse

generator can be turned to set up to 3 m/min. When the

same movement is interrupted by turning the generator in

the negative direction, up to 7 m/min is possible.

If the manual pulse generator is turned in beyond the

limit, the excess pulses generated from the generator

are discarded. Consequently, the reading of the pulse

generator disagrees with the actual traveled distance

made by the interrupt.

(4) Refer to the Manual of MTB for the magnification used in the

manual handle interrupt.
