11.1.2 Automatic Erase Screen Display

The CNC screen is automatically cleared if no keys are pressed during

the period (in minutes) specified with a parameter. The screen is

restored by pressing any key.

Automatic erase screen display

- Clearing the screen

The CNC screen is cleared once the period (minutes) specified with

parameter No. 0016 has elapsed, provided the following conditions are

satisfied:

Conditions for clearing the CNC screen

- Parameter No. 0016 is set to other than 0.

- None of the following keys have been pressed:

MDI keys

Soft keys

External input keys

- No alarm has been issued.

- Restoring the screen

The cleared CNC screen is restored once at least one of the following

conditions is satisfied:

Conditions for restoring the CNC screen

- Any of the following keys has been pressed:

MDI keys

Soft keys

Externally input keys

- An alarm has been issued.

Explanations

- Clearing the screen using + function key

If parameter No. 0016 is set to 0, clearing of the screen using the

<CAN> key and a function key (II-11.1.1) is disabled.

CAUTION

Pressing any key while the screen is being cleared

restores the screen.

In such a case, however, the function assigned to the

pressed key is initiated.

Do not press the <DELETE>, <INSERT>, or

<ALTER> key to restore the screen, therefore.

CAN
