B-63784EN-1/01 OPERATION 8.EDITING PROGRAMS

- 269 -

Replacing all the occurrences of an address without confirmation

Procedure

Method 1

(1) Press the [ALTER] soft key.

(2) Key in the address to be replaced.

(3) Press the [(ADDRESS)] soft key.

(4) Key in a new address.

(5) Press the [EXEC] soft key.

The system searches for the first occurrence of the address

and the cursor is positioned to the address.

(6) Press the [EXEC] soft key.

All the occurrences of the address to be replaced are

replaced.

(7) To end the replacement prior to the end of the search, press

the [STOP] soft key.

(8) When the replacement ends, the total number of

replacements is displayed.

Method 2

(1) Press the [ALTER] soft key.

(2) Key in the address to be replaced, followed by a new address,

as shown in the example.

Example: To replace U with X, enter U,X.

(3) The subsequent steps are the same as (5) to (8) of method 1.

Method 3

(1) Key in the address to be replaced, followed by a new address,

as shown in the example.

Example: To replace U with X, enter U,X.

(2) Press the [ALTER] soft key.

All the occurrences of the address to be replaced are

replaced.

(3) The subsequent steps are the same as (6) to (8) of method 1.

Limitation

1 Only those words that appear after that to which the cursor is

positioned when replacement starts can be replaced. If the word

to which the cursor is positioned when replacement starts is the

same as that to be replaced, that word will not be replaced.

2 Even comment sections are within a scope of replacement.

Example: If an attempt is made to replace Y in the program having

the comment section (JOB2 XY-PLANE), the Y in

the comment section can be replaced.

Warning

Message Description

DATA NOT FOUND Not a single occurrence of the address to be

replaced can be found.
