B-63784EN-1/01 OPERATION 9.SETTING AND DISPLAYING DATA

- 385 -

Tool offset data output

Method 1 (when neither an output file name nor a file number is

specified)

(1) Press the [PUNCH] soft key.

(2) Press the [NUMBER OFFSET] soft key.

Method 2 (The output file is specified with its file name)

(1) Press the [PUNCH] soft key.

(2) Press the ["FILE NAME] soft key.

(3) Enter a file name.

(4) Press the [FILE NAME"] soft key.

(5) Press the [NUMBER OFFSET] soft key.

Method 3 (The input file is specified with its file number (one of three

methods))

(1) Press the [PUNCH] soft key.

(2) Press the [(FILE #)] soft key.

(3) Enter a file number.

(4) Press the [NUMBER OFFSET] soft key.

Method 4 (The input file is specified with its file number (two of three

methods))

(1) Press the [PUNCH] soft key.

(2) Press the

address key.

(3) Enter a file number.

(4) Press the [NUMBER OFFSET] soft key.

Method 5 (The input file is specified with its file number (three of three

methods))

(1) Press the

address key.

(2) Enter a file number.

(3) Press the [PUNCH] soft key.

NOTE

1 When method 1 is used for tool offset data output

(when neither an output file name nor a file number

is specified) for output to a FANUC Floppy

Cassette, FANUC FA Card, FANUC Handy File, or

memory card, file name TOOL-DAT.TXT is selected

2 For input to or output from a FANUC Floppy

Cassette, FANUC FA Card, or FANUC Handy File,

an input/output file can be specified using a file

name or file number.

3 For input to or output from a memory card, an

input/output file can be specified using a file name.
