B-63784EN-1/01 OPERATION 8.EDITING PROGRAMS

- 233 -

Registering additional programs

A program can be loaded and merged with the program selected on the

CNC.

Procedure

Method 1 (Neither the input file name nor number need be specified)

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [READ] soft key.

(4) Press the [1_PROGRAM] soft key.

(5) Press the [ADD] soft key.

Method 2 (The input file is specified with its file name)

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [READ] soft key.

(4) Press the ["FILE NAME] soft key.

(5) Enter a file name.

(6) Press the [FILE NAME"] soft key.

(7) Press the [1_PROGRAM] soft key.

(8) Press the [ADD] soft key.

Method 3 (The input file is specified with its file number (one of two

methods))

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [READ] soft key.

(4) Press the [(FILE#)] soft key.

(5) Enter a file number.

(6) Press the [1_PROGRAM] soft key.

(7) Press the [ADD] soft key.

Method 4 (The input file is specified with its file number (one of two

methods))

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [READ] soft key.

(4) Press the address key.

(5) Enter a file number.

(6) Press the [1_PROGRAM] soft key.

(7) Press the [ADD] soft key.
