9.SETTING AND DISPLAYING DATA OPERATION B-63784EN-1/01

- 370 -

- Switching between pages

With the page keys

PAGE

, the previous or following groups can be

displayed.

- Selecting a group

Method 1

(1) Press the [GROUP NUMBER] soft key.

(2) Enter a group number.

(3) Press the [EXEC] soft key.

Method 2

(1) Enter a group number.

(2) Press the [GROUP NUMBER] soft key.

- Switching between screens

Pressing the [SIGHT] soft key returns the screen display to the tool life

management directory screen.

- Setting of life count type, life values,

counter, and tool data

Method 1

(1) Press the [INPUT] soft key.

(2) Enter a number you want to set.

(3) Press the [EXEC] soft key.

Method 2

(1) Enter a number you want to set.

(2) Press the [INPUT] soft key.

Method 3

(1) Enter a number you want to set.

(2) Press the

INPUT

key.

NOTE

1 Even if a modification is made to a life value or life

counter value, the tool state and tool change signal

are not affected.

2 After making a life count type change, set a life value

and life counter value again.
