8.EDITING PROGRAMS OPERATION B-63784EN-1/01

- 266 -

Replacing all the occurrences of a character string without

confirming each occurrence

Procedure

Method 1

(1) Press the [ALTER] soft key.

(2) Key in the word or character string to be replaced. A list of

words can also be keyed in.

(3) Press the [(WORD)] soft key.

(4) Key in a new word or a character string. Multiple words can

also be keyed in.

(5) Press the [EXEC] soft key.

The system searches for the first occurrence of the character

string to be replaced and the cursor is positioned to the string.

If a list of multiple words is to be replaced, the cursor is

positioned to the last word.

(6) Press the [EXEC] soft key.

All the occurrences of the character string are replaced.

(7) To end the replacement before the completion of the search,

press the [STOP] soft key.

(8) When replacement ends, the total number of replacements is

displayed.

Method 2

(1) Press the [ALTER] soft key.

(2) Key in the word or character string to be replaced, followed

by a new word or character string, as shown in the example.

Multiple words to be replaced and multiple new words can

be entered.

Example: To replace G90 with G91, enter G90,G91.

(3) The subsequent steps are the same as (5) to (8) in method 1.

Method 3

(1) Key in the word or character string to be replaced, followed

by a new word or character string, as shown in the example.

Multiple words to be replaced and multiple new words can

be entered.

Example: To replace G90 with G91, enter G90,G91.

(2) Press the [ALTER] soft key.

The system searches for the first occurrence of the character

string to be replaced and the cursor is positioned to the string.

If a list of multiple words is to be replaced, the cursor is

positioned to the last word.

(3) The subsequent steps are the same as (6) to (8) in method 1.
