7.ALARMS AND SELF DIAGNOSTC FUNCTIONS OPERATION B-63784EN-1/01

- 220 -

- Input format

x x x x x x x * x x x x x x x x * x x x x x x x x

Alphanumeric Kanji/hiragana Alphanumeric

Describe alphanumeric characters directly. Kanji and hiragana

character code must be enclosed by an asterisk (*). Either FANUC

code or JIS code can be selected as the character code by setting bit 6

(JIS) of parameter No. 2286. A name can consist of up to 24

alphanumeric characters (one kanji or hiragana character is counted as

two alphanumeric characters).

Example: To enter "TABLE," specify the following:

FANUC code : TABLE*13AE08DA0738*

JIS code : TABLE*3D61336A4C7D*

NOTE

Symbols *, [, ], (, ), and ; cannot be included in an item

name.

Setting the service life

1) Position the cursor to the desired service life by using the cursor

keys .

2) Key in a time. The set value must be between 0 and 999999

(hours).

3) Press the

[INPUT]

soft key or the

INPUT

key.

The service life and remaining time are set to the same value, and

the count type is initialized.

4) When a time is keyed in, after which the [+INPUT] soft key is

pressed, the set value is added to the existing service life. The

value is also added to the remaining time.

NOTE

If an item name is not set, the service life cannot be

set.

Setting the remaining time

1) Position the cursor to the desired remaining time by using the

cursor

keys .

2) Key in a time. The set value must range from 0 to 999999 (hours).

3) Press the

[INPUT]

soft key or the

INPUT

key.

4) When a time is keyed in, and the [+INPUT] soft key is pressed, the

set value is added to the existing remaining time.

NOTE

If no item name is set, the remaining time cannot be

set.
