Series 15i/150i-MB Operators manual Page 345

Operators manual
B-63784EN-1/01 OPERATION 9.SETTING AND DISPLAYING DATA
- 323 -
Input operation of custom macro common variables
Custom macro common variables can be entered from an external
input/output device.
- Mode setting
Set MDI mode.
- Input procedure
Method 1 (Neither the input file name nor number need be specified)
(1) Press the [READ] soft key.
(2) Press the [COMMON VARIABLE 2] soft key.
Method 2 (The input file is specified with its file name)
(1) Press the [READ] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press the [COMMON VARIABLE 2] soft key.
Method 3 (The input file is specified with its file number (one of three
methods))
(1) Press the [READ] soft key.
(2) Press the [(FILE#)] soft key.
(3) Enter a file number.
(4) Press the [COMMON VARIABLE 2] soft key.
Method 4 (The input file is specified with its file number (two of three
methods))
(1) Press the [READ] soft key.
(2) Press the
N
address key.
(3) Enter a file number.
(4) Press the [COMMON VARIABLE 2] soft key.
Method 5 (The input file is specified with its file number (three of three
methods))
(1) Press the
N
address key.
(2) Enter a file number.
(3) Press the [READ] soft key.
The entered value of a custom macro common variable is automatically
stored into CNC memory.
