8.EDITING PROGRAMS OPERATION B-63784EN-1/01

- 242 -

Outputting all programs

Procedure

Method 1 (Neither the output file name nor number need be specified)

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [PUNCH] soft key.

(4) Press the [ALL] soft key.

Method 2 (The output file is specified with its file name)

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [PUNCH] soft key.

(4) Press the ["FILE NAME] soft key.

(5) Enter a file name.

(6) Press the [FILE NAME"] soft key.

(7) Press the [ALL] soft key.

Method 3 (Specified with its file number (one of two methods))

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [PUNCH] soft key.

(4) Press the [(FILE#)] soft key.

(5) Enter a file number.

(6) Press the [ALL] soft key.

Method 4 (Specified with its file number (two of two methods))

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [PUNCH] soft key.

(4) Press the address key.

(5) Enter a file number.

(6) Press the [ALL] soft key.
