8.EDITING PROGRAMS OPERATION B-63784EN-1/01

- 280 -

8.12 DELETING PROGRAMS

Any program can be deleted.

Deleting a single program

Procedure

Method 1

(1) Press the [DELETE PRGRAM] soft key.

(2) Press the [(PROG)#] soft key.

(3) Key in the program number of the program you want to

delete.

(4) Press the [EXEC] soft key.

Method 2

(1) Press the [DELETE PRGRAM] soft key.

(2) Press the address key.

(3) Key in the program number of the program you want to

delete.

(4) Press the [EXEC] soft key.

Method 3

(1) Press the address key.

(2) Key in the program number of the program you want to

delete.

(3) Press the [DELETE PRGRAM] soft key.

Deleting the currently selected program

Procedure

(1) Press the [DELETE PRGRAM] soft key.

(2) Press the [THIS] soft key.
