4.AUTOMATIC OPERATION OPERATION B-63784EN-1/01
- 180 -
- Relationship with signals
The operation is related to signals as listed below:
Table 4.15(c)
Interrupt type Setup type
Absolute on/off Not affected
(always off)
Affected
Interlock Affected. If the signal is on, operation is not
carried out.
Machine lock Affected. If the signal is on, operation is not
carried out.
Mirror image Not affected. Even if the signal is on, a positive
command moves the machine in the positive
direction.
- Indication
The indication is as follows:
Table 4.15(d)
Interrupt type Setup type
Absolute coordinates Not updated Updated
Relative coordinates Updated Updated
Machine coordinates Updated Updated
