10.DISPLAY OPERATION B-63784EN-1/01

- 534 -

- Cycle

The cycle for storing data is set. Select the cycle from 8 ms, 16 ms, and

32 ms. The setting is written in bits 0 and 1 (TQ1 and TQ2) of

parameter No. 4660.

- Axis setting

The fine torque sensing function allows data for four axes to be stored.

The axis numbers for four target axes are set.

For a servo axis, set a controlled axis number ranging from 1 to the

maximum number of controlled axes. For a spindle, set a spindle

number ranging from -1 to -(the maximum number of controlled

spindles), where the sign of the spindle number is inverted. When 0 is

set, there is no target axis.

The setting is written in parameter Nos. 4670 to 4673.

NOTE

When 0 is set for target axis N for fine torque sensing,

the settings for target axis N+1 and the subsequent

axes are ignored, and 0 is assumed to be set.

- Servo load torque output

When a servo axis is set as a target axis, set the load torque output

function for the target controlled axis to on. If this function is off, the

load torque data for the specified target axis is not stored. The setting is

written in bit 0 (ABN) of parameter No. 1958.

Operation

- Moving the cursor

Use the cursor keys to move the cursor to the parameter you

want to set.

When setting SAMPLE DATA SAVE and CYCLE, use the cursor key

to move the cursor and make selections.
