10.DISPLAY OPERATION B-63784EN-1/01

- 522 -

Explanation

- Wildcard characters (* and ?)

An asterisk (*) represents any character string, while a question mark

(?) represents any one character. They, therefore, allow searches such

as the following.

Table 10.16 Examples of Using Wildcard Characters

Character

string

Programs to search for

* All programs having program names.

*ABC Programs whose program names end with ABC.

ABC* Programs whose program names start with ABC.

*ABC* Programs whose program names contain ABC.

?A?C Programs whose program names are four characters in length, with

the second character being A, and which end with C.

??A?C Programs whose program names are five characters in length, with

the third character being A, and which end with C.

123*456 Programs whose program names start with "123" and end with "456".

NOTE

If programs using asterisks (*) and question marks (?) in

their program names are formed into a group, different

programs may be handled as if they belong to that

group.

Example

Suppose that there are three programs

O100(A*B-MAIN)

O110(A*B-SUB)

O120(ABC).

If grouping is performed with character string "A*B*"

to group programs whose program names start with

"A*B," the program with name O120(ABC) is

handled as if it belonged to that group.

- Retention of the searched-for group

Once a search for a group has been performed, the program directory

for that group is retained until a search for another group is made or the

power is disconnected.

- Group last searched for

To redisplay the program directory of the group last searched for, after

switching from the group-by-group program directory screen to another

screen, click soft keys [DIR.GRP] and [PRV_ GRP]. There is no need

to key in the program name again.

Warnings

Message Description

DATA NOT FOUND A group of programs with the specified character string

cannot be found.
