B-63784EN-1/01 OPERATION 7.ALARMS AND SELF DIAGNOSTC FUNCTIONS

- 225 -

Input/output file format

Periodic maintenance data

G10 L60 P1 [n] Aa Rr Qq ;

G10 L60 P2 [n] Aa Rr Qq ;

G10 L60 P3 [n] Aa Rr Qq ;

Item selection menu (machine) data

G10 L61 P1 [n] ;

G10 L61 P2 [n] ;

G10 L61 P3 [n] ;

G10 L60 : Specifies periodic maintenance data.

G10 L61 : Specifies item selection menu (machine) data.

P : Item number (1 to 10)

[n] : Item name enclosed in [ ]. Item names must conform to the

input format described previously.

A : Life time (0 to 999999)

R : Remaining time (0 to 999999)

Q : Count type

0 : No counting

1 : All time

2 : Power on

3 : Automatic operation

4 : Cutting

Input from an NC program

Data can also be input by executing an input/output file as an NC

program.

NOTE

1 No macro statement can be specified in a

G10L60(61) command block.

2 An item name must be specified following

G10L60(61). If an item name is specified in an invalid

position, the item name is assumed to have been

omitted. As a result, that data having the

corresponding item number is deleted.

Input/output on another screen

Data input/output on the periodic maintenance screens can also be

input/output on the floppy disk list screen and memory card screen. For

details, see Section II-10.12, "Floppy Disk List Screen," and Section

II-10.13, "Memory Card Screen."

Alarm

Number Message Contents

SR0125 ILLEGAL EXPRESSION FORMAT

The description of the custom macro statement is

erroneous.

The format of the parameter data is erroneous.
