B-63784EN-1/01 OPERATION 9.SETTING AND DISPLAYING DATA

- 379 -

Selecting and setting tool offset data

Entering and modifying tool offset data

Method 1

(1) Position the cursor to the data you want to enter or modify.

(2) Press the [INPUT] soft key.

(3) Enter data.

(4) Press the [EXEC] soft key.

Method 2

(1) Position the cursor to the data you want to enter or modify.

(2) Enter data.

(3) Press the [INPUT] soft key.

Method 3

(1) Position the cursor to the data you want to enter or modify.

(2) Enter data.

(3) Press the

INPUT

key.

Offset data increment system

As an offset, a number with or without a decimal point can be entered.

The increment system of an offset depends on the parameter settings, as

indicated below.

Parameter Offset value increment system (valid data range)

OFE OFD OFC OFA Metric input Inch input

0 0 0 1 0.01

(±9999.99)

0.001

(±999.999)

0 0 0 0 0.001

(±9999.999)

0.0001

(±999.9999)

0 0 1 0 0.0001

(±9999.9999)

0.00001

(±999.99999)

0 1 0 0 0.00001

(±9999.99999)

0.000001

(±999.999999)

1 0 0 0 0.000001

(±999.999999)

0.0000001

(±99.9999999)

OFA : Bit 0 of parameter No. 6002

OFC : Bit 1 of parameter No. 6002

OFD : Bit 0 of parameter No. 6004

OFE : Bit 0 of parameter No. 6007
