4.BUILDING A SAFE SYSTEM OPERATION B-62924EN/04

- 94 -

4.1 SYSTEM SAFETY

The PROFIBUS-DP Master function manufactured by FANUC is

designed so that all DI signals are set to 0 when communication is not

performed normally. For this reason, to enable or disable a function

with a DI signal, build the system so that the system continues to

operate safely when the signal is set to 0.

PROFIBUS-DP communication employs a master-slave

communication mode. For this reason, ensure that the master station

always monitors the status of each slave to ensure safe system

operation.

For example, the master station can read and check the diagnose data

for each slave station to determine whether communication with the

slave station is being performed normally. A check method with using

no diagnose data is also supported. A signal for indicating normal

communication is provided in DI/DO data to be exchanged, and is

monitored to determine whether communication between the master

station and a slave station is performed normally.

As described above, for the master station, provide safety provisions

to ensure that the system is not started or is stopped safely if the

system is not ready for execution or if an error occurs in the system.

CAUTION

I/O data is not transferred in sync with ladder

execution, so that the concurrency of I/O data is not

guaranteed.

Table 4-1 indicates information about the processing to be performed

for the major communication states in the FANUC master station. By

referring to Table 4-1, build a safe system.
