Profibus-DP Board Operators manual Page 150

Operators manual

Page of 322

/ 322

5.PROFIBUS FOR THE Power Mate-D/H CONNECTION B-62924EN/04

- 140 -

5.3 SIGNALS

5.3.1 PROFIBUS Interface

<1> DI signals: X1032 to X1063 (up to 256 points)

<2> DO signals: Y1032 to Y1063 (up to 256 points)

5.3.2 Built-in I/O Machine Interface

<1> DI signal (DC input signal B: 16 points)

76543210

X1000

SKIP *RILK *ESP SKIP4 SKIP3 SKIP2

CE49- B05 A06 B04 A04 B03 A03 B02 A02

76543210

X1002

*DEC6 *DEC5 *DEC4 *DEC3 *DEC2 *DEC1

CE49- B10 A10 B09 A09 B08 A08 B07 A07

X1000.0, X1000.1, X1000.2, and X1000.7 are common-switchable

DC input signals B.

X1002.0, X1002.1, X1002.2, and X1002.7 are common-switchable

DC input signals B.

X1000.3 to X1000.6 and X1002.3 to X1002.6 are DC input

signals B.

NOTE

To use the above functions (*ESP, *RILK, SKIPn,

*DECn), set bit 3 (BIO) of parameter No. 3001 and

parameter No. 3005.

X1001, X1003 to X1031, X1064, and above cannot

be used.

<2> DO signals (source type output signals: 2 points)

76543210

Y1000

CE49- B11 A11

NOTE

1 Y1000.2 to Y1000.7, Y1001 to Y1031, Y1064, and

above cannot be used.

2 Refer to Item for "Input/Output Signal Specifications"

in the "FANUC Power Mate-Model H Connection

Manual" for an explanation of the rules governing

input/output signals.

3 The maximum load current for the source-type

output signal is 1.4 A.
