SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

CAUTION

When assigning addresses, pay careful attention to the following points:

1 Ensure that the specified DI and DO areas do not overlap one another.

2 Ensure that specified addresses do not overlap a work area used for a

ladder program.

3 Use the R area only. (When using the PMC-SB5, be careful not to

exceed R1499. When using the PMC-SB6 or the PMC-NB6, be careful

not to exceed R2999.)

(4) STATUS on Screen 1-12 indicates the state of the DP-Slave. Each item under

STATUS has the meaning described below.

CONFIG STATUS

This item indicates whether slave parameter CONFIG DATA of the

DP-Master matches the configuration data recognized by the

DP-Slave. If there is a mismatch, normal communication cannot be

performed.

FF: Initial state

00: State in which normal communication is being performed

(match)

03: State in which received configuration data cannot be accepted

PARAM STATUS

This item indicates whether slave parameter USER PRM DATA of

the DP-Master matches the parameter data recognized by the

DP-Slave. If there is a mismatch, normal communication cannot be

performed.

FF: Initial state

00: State in which normal communication is being performed

(match)

03: State in which received parameter data cannot be accepted

WATCHDOG STATUS

This item indicates the connection state of the communication link

with the DP-Master.

00: Connected

01: Disconnected
