B-62924EN/04 OPERATION 1.16i/18i/21i-A/B, Power Mate i-D/H, AND 16/18-C

- 33 -

1.2.5 Updating DI/DO Data for the Master Function

When creating a ladder program, fully consider the data refresh time

and data simultaneity described below.

Data refresh time

The data refresh time for the master function means the time required

for updating DI/DO data for all slave stations that is allocated in the R

area of the PMC by address assignment.

NOTE

DI/DO data only for the slave stations for which

ENABLE is set as a slave parameter is to be

updated.

In this section, a slave station for which ENABLE is

set is described as a communication slave station.

When only the master function is used

The data refresh time for the master function is indicated by

REFRESH TIME on Screen 1-2. When REFRESH TIME : X MSEC

[Y + Z] is assumed, the meaning of each item is as follows:

X: Data refresh time (= Y + Z)

Y: One-scan time within the communication board (msec)

Z: One-scan time within the CNC (msec)

The one-scan time indicates the DI/DO processing time for all

communication slave stations.

The number of digits that can be displayed is 3 for X, 3 for Y, and 4

for Z. If the number of digits is exceeded, OVR or OVER is displayed,

and it does not affect communication.

CAUTION

Note that DI/DO data may not be updated within the

time displayed for REFRESH TIME in either of the

following cases:

- The status of at least one communication slave

station is changing every moment.

(In this case, diagnose data must be updated.)

- A service is being received from a class-2 master

station every moment.

Y: The one-scan time within the communication board depends

greatly on the bus parameter setting. When the baud rate is 12

Mbps and normal communication is performed with all slave

stations, however, the value of Y is 8 msec in most cases.
