1.16i/18i/21i-A/B, Power Mate i-D/H, AND 16/18-C OPERATION B-62924EN/04

- 50 -

Tables 1-12 to 1-14 list examples of setting CONFIG DATA for a

master station for reference purposes.

Table 1-12 Examples of “(a) Setting CONFIG DATA for Using Both Input/Output”

Input/output sizes for the

master station

DI/DO sizes set for a

FANUC slave station

CONFIG DATA set for the master station

(equivalent to Module in the GSD file)

(a)-<1>

Input/output sise = 64 / 64

DI/DO SIZE = 64 / 64

Data length: 3

Data: C0 3F 3F

(a)-<2>

Input/output sise = 122 / 122

DI/DO SIZE = 122 / 122

Data length: 6

Data: C0 3F 3F C0 39 39

(a)-<3>

Input/output sise = 64 / 128

DI/DO SIZE = 128 / 64

Data length: 5

Data: C0 3F 3F 80 3F

(a)-<4>

Input/output sise = 1 / 192

DI/DO SIZE = 192 / 1

Data length: 7

Data: C0 3F 00 80 3F 80 3F

(a)-<5>

Input/output sise =1 / 243

DI/DO SIZE = 243 / 1

Data length: 9

Data: C0 3F 00 80 3F 80 3F 80 32

(a)-<6>

Input/output sise =128 / 64

DI/DO SIZE = 64 / 128

Data length: 5

Data: C0 3F 3F 40 3F

(a)-<7>

Input/output sise = 192 / 1

DI/DO SIZE = 1 / 192

Data length: 7

Data: C0 00 3F 40 3F 40 3F

(a)-<8>

Input/output sise = 243 / 1

DI/DO SIZE = 1 / 243

Data length: 9

Data: C0 00 3F 40 3F 40 3F 40 32

(a)-<9>

Input/output sise = 65 / 129

DI/DO SIZE = 129 / 65

Data length: 8

Data: C0 3F 3F C0 3F 00 80 00

(a)-<10>

Input/output sise =129 / 65

DI/DO SIZE = 65 / 129

Data length: 8

Data: C0 3F 3F C0 00 3F 40 00

Table 1-13 Examples of “(b) Setting CONFIG DATA for Using Only Output”

Input/output sizes for the

master station

DI/DO sizes set for a

FANUC slave station

CONFIG DATA set for the master station

(equivalent to Module in the GSD file)

(b)-<1>

Input/output sise = 0 / 64

DI/DO SIZE = 64 / 0

Data length: 2

Data: 80 3F

(b)-<2>

Input/output sise =0 / 128

DI/DO SIZE = 128 / 0

Data length: 4

Data: 80 3F 80 3F

(b)-<3>

Input/output sise = 0 / 192

DI/DO SIZE = 192 / 0

Data length: 6

Data: 80 3F 80 3F 80 3F

(b)-<4>

Input/output sise = 0 / 244

DI/DO SIZE = 244 / 0

Data length: 8

Data: 80 3F 80 3F 80 3F 80 33

Table 1-14 Examples of “(c) Setting CONFIG DATA for Using Only Input”

Input/output sizes for the

master station

DI/DO sizes set for a

FANUC slave station

CONFIG DATA set for the master station

(equivalent to Module in the GSD file)

(c)-<1>

Input/output sise =64 / 0

DI/DO SIZE = 0 / 64

Data length: 2

Data: 40 3F

(c)-<2>

Input/output sise = 128 / 0

DI/DO SIZE = 0 / 128

Data length: 4

Data: 40 3F 40 3F

(c)-<3>

Input/output sise =192 / 0

DI/DO SIZE = 0 / 192

Data length: 6

Data: 40 3F 40 3F 40 3F

(c)-<4>

Input/output sise = 244 / 0

DI/DO SIZE = 0 / 244

Data length: 8

Data: 40 3F 40 3F 40 3F 40 33

NOTE

For a FANUC slave station, a total of 244 bytes can

be set for the DI/DO sizes.
