Profibus-DP Board Operators manual Page 259

Operators manual

Page of 322

/ 322

22/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

The following error message may be displayed at the lower left of Screen 1-6. In this

case, take appropriate action, referencing the table below.

Table 1-9 Error messages of Screen 1-6

Message Caution and action

“INVALID INPUT” Invalid value was inputted.

(For example, in the case of attempting

to input a letter into the parameter of a

numerical attribution.)

“ INVALID RANGE”

The inputted value is exceeding the

range.

“INVALID IDX EXISTS”

In slave index table, there is the invalid

line that the ‘NO’ and ‘NSL’ is not being

configured.
