Profibus-DP Board Operators manual Page 270

Operators manual

Page of 322

/ 322

33/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

1.2.6 Updating DI/DO Data for the Master Function

When making a ladder program, fully consider “Data refresh time”, “Data simultaneity”

and “Relation with ladder program” described below.

Data refresh time

The data refresh time for the master function means the time required for updating DI/DO

data for all slave stations that is allocated in the R area of the PMC by address

assignment.

NOTE

-The processing time of a ladder program is not included in the data

refresh time.

-It should be considered that the reaction time is twice data refresh

time at the best. (The reaction time is until receiving the response as

DI data after sending request as DO data.)

-DI/DO data means all DI/DO data of the available slots which are

included in available slaves.

Available slaves are marked with “*” at the position [NO] of the Slave

index screen.

Available slots are marked with either of “---“, “I/O”,”I/-“,”-/O” or “-/-“ at

the position [MOD] of the DI/DO address screen.

When only the master function is used

The data refresh time for the master function is indicated at REFRESH TIME on Screen

1-2.

REFRESH TIME : XXX MSEC ([XXX + XXX] is for maintenance data.)

It is displayed with three digits. If the number of digits is exceeded, OVR or OVER is

displayed, but it does not affect communication.
