Table 1-9 Dianosis data

Diagnose No. Item Description

S0101

Configuration

Status

Indicates whether slave parameter

CONFIG DATA for the DP-Master

matches the configuration data

recognized by the DP-Slave.

S0102

Parameter

Status

Indicates whether slave parameter

USER PARAM DATA of the DP-Master

matches the parameter data recognized

by the DP-Slave.

S0103

WatchDog

Status

Indicates the connection state of the

communication link with the DP-Master.

S0104 Livelist Status

Indicates whether the software of the

slave function is operating normally.

S0105 IDENT NO.

Indicates 00A1 as the identification

number of the DP-Slave using a FANUC

Power Mate CNC.

Procedure using the DPL/MDI

(1) Press the <DGNOS/PARAM> key, then switch the screens, in

order, from Parameter to DIAGNOSE to Pitch Error to Profibus.

Then, Screen 1-13 appears. The displayed items are the same as

those with the DPL/MDI operation package, which will be

described later. See the corresponding description.

S0001 = 0

> S0002 = 0

Screen 1-12
