B-62924EN/04 SUPPLEMENT A.SETTING WHEN EDITION 07 OR EARLIER OF SERIES 6557 IS USED

- 185 -

(4) Each item must be set as described below.

STATION NO.

Set the station number of the DP-Slave.

INPUT DATA

Set an area to be used as a DI data buffer. Set the start

address and size of the buffer.

OUTPUT DATA

Set an area to be used as a DO data buffer. Set the start

address and size of the buffer.

CAUTION

Input and output described below indicate the input

and output viewed from the slave station,

respectively.

Example) For explanation, the example shown in Screen A-9 is

used.

On Screen A-9, the station number of the DP-Slave is 3.

A DI data area and DO data area used as buffers for

communication with the DP-Master are assigned as

described below.

DI data area assignment

R0300

DI data from the DP-Master

R0316

DO data area assignment

R0400

DO data to the DP-Master

R0432
