Profibus-DP Board Operators manual Page 265

Operators manual

Page of 322

/ 322

28/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

Thus, each module parameter should be configured as follows.

SLAVE NO/ SLOT NO Example of Parameter setting

SLAVE NO. = 3

SLOT NO. = 0

MODULE LENGTH = 1

MODULE(HEX) = 00

SLAVE NO. = 3

SLOT NO. = 1

MODULE LENGTH = 2

MODULE(HEX) = 10 20

SLAVE NO. = 3

SLOT NO. = 2

MODULE LENGTH = 1

MODULE(HEX) = 20

SLAVE NO. = 3

SLOT NO. = 3

MODULE LENGTH = 2

MODULE(HEX) = 10 20

Additionally, the following soft keys are available.

[PR.SLT], [NX.SLT] :

A slot number can be moved to the previous or next.

As for the format of GSD file, refer to the documents issued by PROFIBUS

Nutzerorganisation e.V.

The following error message may be displayed at the lower left of Screen 1-8 and 1-9. In

this case, take appropriate action, referencing the table below.

Table 1-12 Error messages of Screen 1-8 and 1-9

Message Caution and action

“INVALID INPUT” Invalid value was inputted.

(For example, in the case of attempting

to input a letter into the parameter of a

numerical attribution.)

“ INVALID RANGE”

The inputted value is exceeding the

range.

“INVALID OPERATION”

The soft key was pressed when the

cursor is being located at an

inappropriate position.

For example, When the cursor is

located at ‘RSV’ of Screen 1-8, the soft

key is pressed.
