Profibus-DP Board Operators manual Page 82

Operators manual

Page of 322

/ 322

2.Series 15i-A OPERATION B-62924EN/04

- 72 -

Each item must be set as described below.

DI/DO ADDRESS AND DI/DO SIZE

Set the area to be used as a DI/DO data buffer.

DIAGNOSE ADDRESS AND DGN DATA SIZE

Set an area for storing diagnose data. For details of standard

diagnose data, see Table 2-4.

NOTE

Diagnose data is classified as standard diagnose

data and extended diagnose data. The DP-Slaves

manufactured by FANUC use standard diagnose

data (6 bytes) only. On the other hand, DP-Slaves

supplied by other manufacturers may use extended

diagnose data of more than six bytes. When using

DP-Slaves supplied by other manufacturers,

determine the size of the diagnose data by

referencing the GSD file of each DP-Slave.
