B-62924EN/04 OPERATION 1.16i/18i/21i-A/B, Power Mate i-D/H, AND 16/18-C

- 45 -

1.3.2 Updating DI/DO Data for the Slave Function

When creating a ladder program, fully consider the data simultaneity

described below.

Data simultaneity

With the FANUC master function and slave function, when DI/DO

signals are handled with a ladder program, data simultaneity is

guaranteed in each of long data (4-byte data) units and word data (2-

byte data) units under the following constraints.

NOTE

If the following constraints are not satisfied,

simultaneity of each data length cannot be

guaranteed.

Data simultaneity for long data (4-byte data)

<1> Use the following commands in the PMC ladder program in 4-

byte units:

DECB, CODEB, DCNVB, COMPB, DSCHB, XMOVB, ADDB,

SUBB, MULB, DIVB, NUMEB, MOVN, EOR, AND, OR, and

NOT

<2> When assigning DI/DO data to R addresses in the PMC area,

follow the rules below depending on the PMC type:

- For the PMC-SB6

Each R address area must start at a 4-byte boundary.

(Example:R0000, R0004, R0008, R0012, . . .)

- For the PMC-SB5, PMC-SA1, or PMC-SA5

Each R address area must start at 2 bytes ahead of a 4-byte

boundary.

(Example: R0002, R0006, R0010, R0014, . . .)

CAUTION

To guarantee long data simultaneity, Edition 08 or

later of series 6557 of CONTROL SOFTWARE must

be used.

Data simultaneity for word data (2-byte data)

<1> Use the following commands in the PMC ladder program in 2-

byte units:

DECB, CODEB, DCNVB, COMPB, DSCHB, XMOVB, ADDB,

SUBB, MULB, DIVB, NUMEB, MOVW, MOVN, EOR, AND,

OR, and NOT

<2> When assigning DI/DO data to R addresses in the PMC area,

each R address area must start at a 2-byte boundary.

Data simultaneity for byte data (1-byte data)

There is no constraint.

Simultaneity is always guaranteed within 1-byte data.
