Profibus-DP Board Operators manual Page 308

Operators manual

Page of 322

/ 322

6/20

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Hiramatsu Newl

istered

TITLE: PROFIBUS-DP Board OPERATOR’S MANUAL

Setting method of address mapping for

PMC-SD7“%I,%Q”

B-62924EN/04-3

FANUC LTD.

04.12.27

DRAW.NO.

NOTE

When PMC address setting is invalid, an error message "INVALID

INPUT" or "INVALID RANGE" is displayed.

Causes :

・ When PMC address name was input, input character was not "M",

"ME", "I" or "Q".

・ When "I/O Link expansion" function is used, input PMC address

name was "I" or "Q".

・ The setting parameter was unavailable for a PMC address %I

or %Q.

・ For a PMC address %M or %ME:

- When PMC address number was input, input value was not

(8*n)+1 [n = from 0 to 7999].

- When PMC Size was input, input value was not from 0 to 244.

- When PMC address number or PMC Size was input, the

specified PMC Area "PMC address number+(PMC Size*8)-1"

exceeded the maximum value 64000 of PMC Area %M

or %ME.

・ For a PMC address %I or %Q:

- When PMC address number was input, input value was not

(8*n)+10001 [n = from 0 to 127].

- When PMC Size was input, input value was not from 0 to 128.

- When PMC address number or PMC Size was input, the

specified PMC Area "PMC address number+(PMC Size*8)-1"

exceeded the maximum value 11024 of PMC Area %I or %Q.

CAUTION

When assigning addresses, pay careful attention to the following points:

(1) Ensure that a specified PMC area (Master function’s DI/DO data area,

diagnose data area, operation mode indication area, Slave function’s

DI/DO data area if Slave function is used) do not overlap one another.

(2) Ensure that the specified addresses do not overlap an area used for a

ladder program.
