Profibus-DP Board Operators manual Page 247

Operators manual

Page of 322

/ 322

10/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

Table 1-3 Bus Parameter Settings Corresponding to Each Transfer Rate

Bus parameter Setting

1: FDL ADD 0 to 125

2: BAUDRATE (Kbps) ≤187.5 500 1500 3000 6000 12000

3: T SL 100 200 300 400 600 1000

4: MIN T SDR 11 11 11 11 11 11

5: MAX T SDR 60 100 150 250 450 800

6: T QUI 0 0 0 3 6 9

7: T SET 1 1 1 4 8 16

8: TTR 65000 65000 65000 65000 65000 65000

9: G 10 10 10 10 10 10

10: HSA 126 126 126 126 126 126

11: MAX RETRY 1 1 1 2 3 4

12: BP FLAG 0 0 0 0 0 0

13: MIN SLAVE INT 1 1 1 1 1 1

14: POLL TIME OUT 1000 1000 1000 1000 1000 1000

15: DATA CONTROL 100 100 100 100 100 100

16: CLASS2 NAME This parameter need not be set.

17: MASTER USER DATA 0 0 0 0 0 0

Viewing this table for parameter setting:

First, determine the value of 2: BAUDRATE. Then, set the other parameters according to the set baud rate.

NOTE

For multiple master communication, satisfy the following conditions:

- The value set for 1:FDL ADD for a master station is not used as

another master station number.

- The same values are set for bus parameters 2 to 11 for all master

stations.

- When a larger value is set for T SET, T SL is larger than T ID1.

(T ID1 = 33 + 2 + 2 × T SET + T QUI)
