Profibus-DP Board Operators manual Page 273

Operators manual

Page of 322

/ 322

36/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

When both the master and slave functions are used together

In this case, the data refresh time is similar to that described in "When only the master

function is used" above.

However, SIZE: DI/DO data size in expression (A) is as follows:

SIZE = SIZE

mas

+ SIZE

slv

SIZE

mas

: DI/DO data size for the master function

SIZE

slv

: DI/DO data size for the slave function

Example of calculating the data refresh time

[Conditions]

• CNC model: 16i/18i/21i-A/B

• Communication slave station settings for the master function :

- Slave No. 3: N_slot=1, SIZE = 122/122

- Slave No. 4: N_slot=1, SIZE = 122/122

- Slave No. 5: N_slot=1, SIZE = 122/122

- Slave No. 6: N_slot=1, SIZE = 122/122

• Settings for the slave function : DI/DO SIZE = 8/8

[Calculation]

• First group

- Calculation for slave No. 3 and 4:

37×2 + 8.6×(1+1) + 1.3×(244+244+16)=746 <750

→ N_slave, N_slot and SIZE indicate the maximum values.

Slave No 3 and 4 are first group.

- Calculation for slave No. 3 to 5:

37×3 + 8.6×(1+1+1) + 1.3×(244+244+244+16)=1109 >750

→ The values of N_slave, N_slot and SIZE should be cleared.

• Second group

- Calculation for slave No. 5 to 6:

37×2 + 8.6×(1+1) + 1.3×(244+244+16)=746 <750

→ Slave No 5 and 6 are second group and calculation for all

communication slave stations is complete. Thus slave group

(n) is determined to be 2.

Thus, the data refresh time is 16 msec for this example.
