Table 1-6 Standard Diagnostic data

Item Description

STATION STATUS 3 The state of a DP-Slave is indicated.

MASTER ADDRESS

(Size: 1 byte)

The address of the DP-Master that set the parameters of the DP-Slave is set. If the

parameters are not set by the DP-Master, 255 is set.

IDENT NUMBER

(Size: 2 bytes)

The identification number of a DP-Slave is set.

The following error message may be displayed at the lower left of Screen 1-5. In this

case, take appropriate action, referencing the table below.

Table 1-7 Error messages of Screen 1-5

Message Caution and action

“INVALID INPUT” Invalid value was inputted.

(For example, in the case of attempting

to input a letter into the parameter of a

numerical attribution.)

“ INVALID RANGE”

The inputted value is exceeding the

range.

“ ’NO’ OVERLAP”

The inputted slave number ‘NO’ is

overlapping with the other.

“ ’NSL’ SUM OVER”

The total of slot number “NSL” is

exceeding the limit of 48 slots.

“SET ‘NO’ AND ‘NSL’ OF

CURRENT IDX”

The ‘NO’ or ‘NSL’ of the slave indicated

by the cursor is not being configured.

Both ‘NO’ and ‘NSL’ should be set.

“INVALID IDX EXISTS”

In slave index table, there is the invalid

slave which the ‘NO’ or ‘NSL’ is not

configured in.
