Profibus-DP Board Operators manual Page 310

Operators manual

Page of 322

/ 322

8/20

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Hiramatsu Newl

istered

TITLE: PROFIBUS-DP Board OPERATOR’S MANUAL

Setting method of address mapping for

PMC-SD7“%I,%Q”

B-62924EN/04-3

FANUC LTD.

04.12.27

DRAW.NO.

A.2 PMC ADDRESS SETTING FOR SLAVE FUNCTOIN

The method of PMC address setting is described below when using PMC-SD7.

Table PMC address setting when using PMC-SD7

Item. Description

The available PMC address Name is %M, %ME, %I

and %Q.

PMC address Name

Example) "M", "ME", "I", "Q"

For a PMC address %M or %ME:

The available range is from 1 to 63993.

But the following condition has to be satisfied.

Condition) (8*n)+1 [n = from 0 to 7999]

Example) "1", "9", "17", - - - "63993"

For a PMC address %I or %Q:

The available range is from 10001 to 11017.

But the following condition has to be satisfied.

Condition) (8*n)+10001 [n = from 0 to 127]

PMC address Number

Example) "10001", "10009", "10017",

- - - "11017"

For a PMC address %M or %ME:

The available range is from 0 to 244.

(Unit : byte)

Example) "0", "1", "2", - - - "244"

For a PMC address %I or %Q:

The available range is from 0 to 128.

(Unit : byte)

PMC Size

Example) "0", "1", "2", - - - "128"

NOTE

The Limitations to assign a PMC address %I or %Q:

・ I/O Link 2ch and PMC address %I or %Q can't be used at the

same time. Therefore when assigning a PMC address %I or %Q,

"I/O Link expansion" function cannot be used.

・ A PMC address %I is unavailable for a DO data address.

・ A PMC address %Q is unavailable for a DI data address.
