1.16i/18i/21i-A/B, Power Mate i-D/H, AND 16/18-C OPERATION B-62924EN/04

- 26 -

Remarks) Explanation of terms used in the above table

Sync control

command

: Command for specifying operation in Sync

mode. When operation is performed in Sync

mode, the DP-Slave updates the output signals

only when the Sync control command is

received.

Freeze control

command

: Command for specifying operation in Freeze

mode. When operation is performed in Freeze

mode, the DP-Slave updates input signals only

when the Freeze control command is received.

Disconnection

detection

: Function for checking if data is exchanged

normally between the DP-Master and DP-

Slave. If data is not exchanged after the

disconnection detection time determined by

WD FACT1 and WD FACT2 has elapsed, an

error is assumed.

Bit time : Time (sec) required to send one bit of data at a

specified transfer rate. This is equivalent to the

reciprocal of a transfer rate (bps).

CAUTION

Set values for parameters USER PRM DATA,

CONFIG DATA, and SLAVE USER DATA so that

the total of the three parameter lengths does not

exceed 207.
