Profibus-DP Board Operators manual Page 250

Operators manual

Page of 322

/ 322

13/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

Table 1-5 Parameters of Slave Index setting screen

Parameters Explanation

IDX Index number of slaves

Max.48 slaves can be configured.

Slave number

Available slaves are marked with “*” at the slave

number “NO” on the screen.

Range : 0 to 125

Slot number.

The number of I/O module units which are

installed in the corresponding slave station.

As for the detail of “Slot”, please refer to

“Explanation of Slot” below.

NSL

Range : 1 to 24

Note) If both Master and Slave functions are

used at the same time, the range is limited

until 8 units.

Start address of Diagnostic data.

As for the contents of Diagnostic data, please

refer to “Diagnostic data” at the end of this

section.

ADDR

Range : Please refer to “CAUTION” of this

section.

Size of Diagnostic data

DGN

SIZ

Range : 0 to 244 (byte)

[Explanation of Slot]

When a slave station consists of multiple I/O module units, the location which each I/O

module is installed in is called “Slot”.

Basic module

(Power supply

unit etc.)

I/O module I/O module

I/O module

Slot number 0 Slot No. 1 Slot No. 2 Slot No. n

In the above figure, NSL (Slot number) becomes equal to “n+1”.

Some of module units may not have an input/output interface. Even if so, this module

must be counted as one slot.
