TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

Additional explanation of PROFIBUS-DP Master function

I/O Module Assignment function

When using the I/O Module Assignment function with the PROFIBUS application software 6558,

please refer to this additional explanation, instead of Section 1.2.2, 1.2.3 and 1.2.4 of FANUC

PROFIBUS-DP board OPERATOR’S manual.

CAUTION

After configuring DI/DO signals, please confirm that the signals

behave correctly with the conditions of ensuring the safety.

The operation without the above confirmation may cause critical

accidents.

Outline of Master function

CNC type

LCD-mounted type Series 16i/18i/21i-A/B,

Stand-alone type Series 16i/18i/21i-A,

Power Mate i-D/H,

Series 16/18-C

CONTROL SOFTWARE 6558 Series

Range of valid master station

numbers

0 to125

Range of valid slave station

numbers for which

communication can be

performed

0 to125

The maximum number of the

slaves which can be connected

48 slaves

The maximum number of the I/O

modules per every slave

24 modules per a slave

(The sum of slaves and modules

is limited to 48 unit in the whole of network.

When using both Master and Slave,

the number of modules is limited until 8 units

per a slave.)

Maximum DI/DO data size per

slave station

244 bytes

(Total of DI/DO)

Maximum user parameter data

size per slave station

206 bytes

Maximum diagnose data size per

slave station

242 bytes
