Profibus-DP Board Operators manual Page 256

Operators manual

Page of 322

/ 322

19/42

SHEETDESCRIPTIONDESIGN DATE EDIT

01 Mutai Newl

istered

TITLE: Additional explanation of

PROFIBUS-DP Master function

(I/O Module Assignment function)

B-62924EN/04-1

FANUC LTD.

02.10.7

DRAW.NO.

Table 1-8 shows the explanations of the slave parameters

For details, refer to the documents issued by PROFIBUS Nutzerorganisation e.V.

Table 1-8 Slave Parameters

Item Description

IDENT NO. DP-Slave identification number.

This parameter specifies the identification number of a DP-Slave to be connected.

SLAVE FLAG Slave specification bit flag.

Bit 7: Active

0: Does not perform communication with the DP-Slave.

1: Performs communication with the DP-Slave.

Bit 6: New_Prm

0: Does not send new parameter data to the DP-Slave.

1: Sends new parameter data to the DP-Slave.

Bits 5 to 0: Reserved (to be service to 0)

SLAVE TYPE Manufacturer-specified type indication for the DP-Slave.

LOCK REQ, UNLOCK

REQ

When LOCK_REQ=ON and UNLOCK_REQ=OFF are set, the DP-Slave disables the

DP-Master from modifying the parameters.

When LOCK_REQ=OFF and UNLOCK_REQ=ON are set, the DP-Slave allows the

DP-Master to modify the parameters.

SYNC REQ When ON is set, the Sync control command can be used.

FREEZE REQ When ON is set, the Freeze control command can be used.

WD REQ When On is set, disconnection detection is performed.

WD FACT1, WD

FACT2

Coefficients for disconnection detection time determination.

10 × WD_FACT1 × WD_FACT2 (msec)

MIN TSDR Minimum wait time until a response is returned to the DP-Master. (Unit: Bit time)

GROUP IDENT This parameter specifies groups for the DDLM_Global_Control instruction. Each bit

represents a group. Up to eight groups can be specified.

USER PRM DATA User parameter data.

Data necessary for the slave parameters and specified by the manufacturer.

CONFIG DATA Configuration data.

Data for specifying information such as the size of I/O data to be exchanged between the

DP-Master and DP-Slave.

SLAVE USER DATA Slave user data.

Data specified by the manufacturer to indicate the characteristics of the DP-Slave.
