Profibus-DP Board Operators manual Page 192

Operators manual

Page of 322

/ 322

A.SETTING WHEN EDITION 07 OR EARLIER OF SERIES 6557 IS USED SUPPLEMENT B-62924EN/04

- 182 -

For details, refer to the following documents issued by PROFIBUS

Nutzerorganisation e.V.:

¡ PROFIBUS STANDARD DIN 19 245 Part 1

This document describes data transfer, access methods, protocols,

and interfacing with the application layer.

¡ Draft Standard PROFIBUS-DP DIN 19 245 Part 3

This document describes an abstract model of the PROFIBUS-

DP communication function, and so forth.

Soft key [INIT] on Screen A-7 clears the value of each address

assignment parameter (the address specification fields are set to

R0000). So, specify valid values.

Example) For explanation, the example shown in Screen A-7 is

used.

On Screen A-7, SLAVE NUMBER is 3. So, addresses are

assigned to the DP-Slave at station number 3.

DI ADDRESS is R0000, and DI SIZE is 32. So, a 32-byte

DI data area is assigned, starting at R0000, to the DP-

Slave at station number 3, as indicated below.

DO ADDRESS is R0100, and DO SIZE is 16. So, a 16-

byte DO data area is assigned, starting at R0100, to the

DP-Slave of station number 3, as indicated below.

DI data area assignment

R0000

DI data from DP-Slave #3

R0032

DO data area assignment

R0100

DO data to DP-Slave #3

R0116

For diagnose data, similarly, DGN ADDRESS is R0200,

and DGN DATA SIZE is 6. So, a 6-byte diagnose data

area is assigned, starting at R0200, to the DP-Slave of

station number 3, as indicated below.

Diagnose data area assignment

R0200

Diagnose data of DP-Slave #3

R0206
